Gobo Projectors
Projectors – Gobo Projectors are so versatile you can’t help being impressed and excited at the possibilities for your project. All our Gobo Projectors have energy efficient lamps, low power consumption and yet produce brilliantly clear and sharp images.
Gobo – The key to achieving the best quality results from your projector lies in the Gobo (Projector Disks) itself. We supply the best quality Gobo Disks available in the market and work with the most knowledgeable and experienced designers and manufacturers.
Filters – The Light Projectors can be used to project a colour wash, an image or a moving image onto a surface. All are produced with the same projector; you just choose the type and design of the Gobo or Gobo Filter
Mapping – this is where we map out the contours and features of your building to create a stunning lighting display specifically designed to bring out the best features in your building or to re-create features of old that have long since crumbled away. Your imagination is the only limit and with our training and advice we’ll help to remove all those limits. Talk to us about your ideas today and gladly share our knowledge and experience.
Signage – Whether projected onto a wall, floor or roof projected signage is great way to keep your safety and informational signs clear and crisp even in high traffic areas such as loading bays or cleanrooms. You can even activate them with sensors, so the message is always noticed!
Golux 1000
The GOLUX 1000 is a powerful projector, thanks to the wide zoom (7,70°-34°). The aluminium body, electronic ballast can be used for long distance, wide architectural and environmental projections.
This projector is by far the brightest, most versatile and efficient among the architectural projectors on the market today. With its 93000 lux at 5 meters and the powerful Zoom (9° – 53°), it can be used both for very long distance (even more than 1km) and for very large projections at a short distance. A cooling system designed for the specific lamp model used guarantees a real lamp life of 900 hours. It has a complete range of accessories including rain cover, pole brackets and much more.
LIGHT SOURCE:Philips MSR Gold 1000 MiniFastFit 1CT/4
LIGHT OUTPUT: 93000 lux @ 5 m (9°)
OPTICS: 9° – 53°
Power Supply
110-240V 50/60 Hz
Maximum power consumption 1200W
Average consumption 1100W
Lamp
Philips MSR Gold 1000 MiniFastFit 1CT/4
Colour temperature: 6,000 K
Average life: 900 hrs
Luminous flux: 82000 lm
Optics
zoom lens (9° – 53°)
Manual focus
Gobo Rotaotr
Body
Aluminium structure
Thermal Data
Forced ventilation cooling
Maximum ambient temperature (Ta max.): 40°
Minimum ambient temperature (Ta min.): -20°
CE Marking
Complies with European Directives:
2014/35 / EU – Safety of Low Voltage Powered Equipment (LVD)
2014/30 / EU – Electromagnetic Compatibility (EMC)
2011/65 / EU – Restriction on use of certain hazardous substances (RoHS)
2006/25 / EC – Photobioligical safety
Weight & Dimensions
Protection rating IP20, with rain cover IP33
Dimensions: 64x38x25 cm
Weight 15 Kg
Electronics
Built-in PFC (pf> 0.98 100-260 Vac full range)
Integrated EMI filter
DSP control
Ballast controlled and programmed in standalone mode, with DMX or interface keypad
Flicker-free output
On/off switch
Short circuit or open circuit protection
DSP controlled fan outputs
DMX controlled Lamp On / Off | Dimmer | Strobe | Fade
Temperature, Switching On / Off , Electrical Parameters, Software Version and Work Time Control Interface
Safety Devices
Bipolar circuit breaker with thermal protection
Automatic power supply interruption in case of overheating
Forced ventilation with axial fans
Gobo LED 80D
With all the renowned, uncountable advantages of the single powerful LED that is fitted with, this brand new IP65 rated GoboLED 80D projects a bright and accurate rendition of graphic designs or logos in outdoor and indoor locations with the help of a dichroic or metal gobo.
Packed with multiple effects, patterns and a motorized zoom, GOBOLED 500 offers broad creative design integration for permanent exterior installations. Fitted with one high power LED, this cutting edge image projector delivers a bright and accurate rendition of graphic designs
GOBOLED 500 is an IP66 image projector, whose aluminium body, fitted with an adjustable mounting yoke, hosts 1 high brightness 6500K power LED. Dimensions: 332mm x 536mm x 454mm. Available in DMX, automatic and Master-Slave mode, it also features linear 0-100% dimmer, RFU (Remote firmware update), and RDM (Remote device management) functions. Additional features: 14 DMX channels; strobe function (27.7 FPS max); electronic blackout; motorized focus; 7°-37° motorized zoom; 7 interchangeable rotating gobos wheel (ø 28.7/22 mm); 16 bit indexing; 4 fixed gobos plus animation effect wheel; 8 colours + white wheel; 2 prisms with variable rotation (8 facets and 3D effect); pulse effect. Power supply: standard 90÷240V / 50-60Hz. Power consumption: 1A @ 230V / 450W. An Electrical Class I appliance, it features integrated electronic thermal protection management. Operating temperature: -30°C to 50°C (-22°F to 122°F).
Source
One high brightness power LED unit (6.500K)
No UV / no infrared
Virtually instant light production (100 ns)
Source Life
The LED light source used has an exceptionally long life: predicted 50,000 hours under normal operating conditions as mentioned by the LED manufacturer
Optics
7°-37° motorized zoom
Linear 0 to 100% electronic dimmer
Strobe function (27.7 FPS max)
Electronic blackout
Motorized focus
7°-37° motorized zoom
7 interchangeable rotating gobos wheel (ø 27/22 mm)
16 bit indexing
4 fixed gobos plus animation effect wheel
8 colours + white wheel
2 prisms with variable rotation (8 facets and 3D effect)
Pulse effect
Digital Control System
RFU (Remote firmware update) function
RDM (Remote device management) function
On-board display for digital data assignment and standalone operation control
DMX, automatic and Master-Slave mode
14 channels of standard DMX 512
Programming software with USB compatible download IP65 box (ordering code AL4118)
Enhanced programming software with ETHERNET compatible download box (IP65 AL4119 or IP20 AL4135)
Wireless DMX control system (AL3360/ AL3362/ AL3364/ AL3366/AL3620)
Wall-TSC (ordering code AL1424)
Spectrum TSC (ordering code AL1425)
WeeZerd 1 (ordering code AL2660)
Electrical specifications
Power supply:
90-240V – 50/60Hz
Power consumption:
1A @ 230V / 450W
Electrical class: I
Meets CE safety standards
CSA certificate of compliance
Housing
Aluminium body with an adjustable mounting yoke
Scratch resistant textured polyester finish, which protects against UV deterioration and general corrosion
Shock resistant, tempered front glass (IK07)
Noiseless ventilation system
IP66 protection rating
IK07
External Operating Limits
-30°C to 50°C
(-22°F to 122°F)
Integrated electronic thermal protection management
Weight
30KG
Divum
The Divum30K is an extraordinary performance LED projector, thanks to the brand new 30,800 Lumen COB LED. This projector is ideal for bright and brilliant all year round projections. The Effect version includes quality camera lens and animation disc accessory to ensure high resolution of snowfall and shooting stars effect.
LED Christmas Projector DIVUM is a high-efficiency outdoor LED projector with IP54 protection degree.
Equipped with a LED light source of 32,000 lumens and optics of extraordinary brightness and definition, it is the ideal projector for permanent Christmas projections on buildings, churches and monuments, thanks to a uniform and luminous beam that allows you to project from up to 50 meters away.
Among its rivals in the category of Christmas LED projectors, it clearly stands out in terms of brightness, ranking first in terms of efficiency.
Power Supply
110-240V 50/60 Hz
Power consumption 250W
Lamp
High Efficiency White COB LED
Colour temperature: 6,000 K
Average life: 50.000 hrs
Luminous flux: 30.800 lm
Optics
Fixed lens aperture 39°
Manual focus
Accessory
Gobo Rotator that allows you to rotate a gobo.
Body
Steel and Aluminium structure
Weight & Dimensions
Protection rating IP54
Dimensions: 43x23x36,5 cm
Weight 12 Kg
