4 Zone Wall Panel Controller
2.4GHz wireless transmitting 4 zone wall controller with sensitive touching panel design. Touch the panel to choose the color from 16 million colors. Color temperature slider to adjust the CCT from 2700K to 6500K. Easy installation, safe and reliable. Simple but multi functional with compatible 4 zone RGB/RGBW/RGB+CCT series. Adjust CCT under white light mode. Change colour saturation under colour mode. High precision touch screen IC, touch screen is very stable.
- High precision capacitive touch IC.
- 2.4G RF wireless transmission technology.
- 30m control distance.
- 16 million colours.
- Brightness, color temperature and saturation adjustable.
Working voltage – AC100~240V
Standby power consumption – 0.15W
Transmitting power – 6dBm
RF – 2.4GHz
Control distance – 30m
Modulation method – GFSK
Transmission frequency – 2400-2483.5MHz
Panel size – 86*86*33mm
Note: This 4 zone wall controller is only compatible with our colour changing lights series.
